Features:
-
4 digits LCD display
-
Auto range for all function
-
60 segments analog display
-
Test hold function for easy operation
-
0.01Ω for low Ω range
-
20MΩ for resistance measurement
-
400GΩ for Insulation measurement
-
PC interface with software
-
Datalogging function with 10000 records
Specifications:
Range | Resolution |
Accuracy
|
600V | 0.1V | 1.5%+3 |
Range | Resolution | Accuracy |
600V | 0.1V | 1.5%+3 |
Range
|
Active Region
|
|
< 40Ω
|
Range
|
Resolution
|
Accuracy | |
40Ω
|
0.01Ω
|
1%+2 (<5Ω)
1% (<40Ω) |
Range
|
Resolution
|
Accuracy | |
40Ω~20MΩ
|
0.1Ω~100KΩ
|
1%+2 (<2MΩ)
2%+2 (<20MΩ)
|
|
Voltage
|
Range
|
Resolution
|
Accuracy
|
|
250V |
250KΩ~100GΩ
|
1KΩ~100MΩ
|
2%+3 (<20GΩ)
3%+3 (<50GΩ)
5%+3 (<100GΩ)
|
|
500V |
500KΩ~200GΩ
|
1KΩ~1GΩ
|
2%+3 (<20GΩ)
3%+3 (<50GΩ)
5%+3 (<200GΩ)
|
|
1000V |
1MΩ~400GΩ
|
2%+3 (<20GΩ)
3%+3 (<100GΩ)
5%+3 (<200GΩ)
10%+3 (<400GΩ)
|
||
Standard Accessories:Test lead, large jaw alligator clips, battery, carrying case, software, USB cable, instruction manual |
